Home > Super Duplex Steel Stud Bolts S32760
Request For Our Latest Prices On Super Duplex Steel Stud Bolts S32750 in Istanbul, Turkey!
Istanbul, Turkey-based Yasin Fasteners is one of the leading manufacturers and suppliers of **S32760 Super Duplex Steel stud bolts**, which have been specially developed for deployment in highly corrosive, high-pressure environments. These stud bolts, which boast an extremely high strength along with excellent resistance to pitting, crevice corrosion, as well as stress corrosion cracking, are specifically developed to function under challenging industrial conditions. Yasin Fasteners provides S32760 stud bolts to industries such as offshore oil and gas, marine, chemical processing, and desalination with both standard and special sizes following international quality requirements.
Super Duplex Steel S32760 stud bolts consist of about 25–26% chromium, 6–8% nickel, 3.5–4% molybdenum, and nitrogen. This high-performance alloy provides excellent resistance against chloride-rich environments and severe chemicals. The duplex microstructure of S32760 offers extremely high mechanical strength, with tensile strength of between 800 and 860 MPa and yield strength of between 550 and 620 MPa—almost double that of conventional austenitic stainless steels. Such properties, combined with superior fatigue resistance and heat stability, make S32760 stud bolts the best choice for applications in structurally or corrosively challenging environments.
| Standard | DIN, ASTM, BS and all International Standards |
| Specifications | ASTM A479 & ASME SA479 |
| UNS S32760 Nut and Bolts Size | M3 To M56 3/6″ to 2″ |
| Length | 3 to 200 MM |
| Super Duplex Steel 2207 Machine Screws Size | M1.6 To M12 |
| Duplex Steel 2205 Washers Size | M3 To M56 3/6″ to 2″ |
| Tensile Strength(MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) | Hardness Rockwell C (HR C) | |
| Super Duplex Steel Bolts | 760 | 550 | 15 | 32 Max |
| Phosphorus | Sulphur | Silicon | Carbon | Manganese | Nickel | Molybdenum | Nitrogen | Copper | Chromium |
|---|---|---|---|---|---|---|---|---|---|
| 0.035 % max | 0.02 % max | 0.80 % max | 0.03% Max | 1.20 % max | 6.00 – 8.00 % | 3.00 – 5.00 % | 0.24 – 0.32 % | 0.50 % max | 24.0 – 26.0 % |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Super Duplex Steel S32760 stud bolts find extensive application in offshore oil rigs, subsea pipelines, pressure vessels, and structural joints where seawater exposure and high pressure are prevalent. In the petrochemical and chemical industry, they find application for flange securing, valves, and reactors that process corrosive acids and chlorides. They are also utilized in desalination processes, marine projects, and power generation systems. The high strength, corrosion resistance, and extended service life of S32760 stud bolts make them a trustworthy option for mission-critical use in the world’s most severe operating conditions.
Yasin Fasteners ensures the secure and efficient packaging of Super Duplex Steel Stud Bolts S32760 to maintain their quality during transit. Each stud bolt is carefully inspected and packed in high-strength, corrosion-resistant packaging materials to prevent damage. We offer various packaging options, including bulk boxes and individual containers, tailored to meet your specific requirements. Our packaging solutions are designed to safeguard the integrity of the fasteners and facilitate easy handling and storage, ensuring they arrive in perfect condition.
Yasin Fasteners is a leading manufacturer and supplier of high-quality fasteners in Istanbul, Turkey, with over 8 years of experience serving global industries.
